Sofiano 600-800-1000-1500-2000L

Trailed atomizers with deflector are ideal for large-sized plantations of fruits and vines. The tank is made of polyethylene and consists of three parts: the main one with filter and cover, hand-washing tank with faucet and rinsing tank. The fan is Ø800 mm (8 feathers with the possibility of regulation). Stainless steel tube nozzles holder. Double adjustable brass nozzle with anti-drip and ceramic nozzles. Transmission by one speed multiplier with declutch lever. The filter has the possibility of self-filling from natural sources (wells, reservoirs for water accumulation, sources, etc.). The homogenization of the preparation is accomplished by a hydro-injector. The wheels are adjustable. There is also the possibility of installing fins, electronic pressure regulator and other equipment, as stated in the accessories.



Three tanks: polyethylene with filter and cover 400/600/800L, hand-washing tank 15L with faucet, rinsing tank 40/60/80L;

Total emptying system;

Chassis (metal construction) - painted (car paint);

Two ways pressure regulator;

Adjustable brass nozzle with anti-drip and ceramic plates with hole 0.8 and 1.2mm;

Stainless steel tube nozzles holder;

Transmission of torque using the multiplier MA86/42 (transmission ratio 1:3.12 and 1:4.5) for ø 800 and the multiplier MA502/14 transmission ratio 1:4.53 and 1:3.82, with two speeds ø 700 mm;

Pump: flow rate 96 L/min, maximum pressure 40 bar and 121 L/min. maximum pressure 40 bar. (depending on customer's wishes)

Metal diffuser - painted (car paint)

Fiberglass fan ø 800 mm or ø 700 mm with adjustable blades with angle 20 - 45°;

Filter with self-filling possibility;

Connection on filter to draw water from natural sources;

Hydraulic injector;


Top directional fins for diffusor D.700mm;

Electronic pressure regulator;

2 long-range end nozzles-top nozzles;

Cardan L=800mm Φ 22x54mm, with PVC plastic protection;

Self-filling system (5m ribbed hose + suction basket);

Surcharge for powder mixer on filter tank;

Hydraulic injector (mixer + injector);

Tank rinsing - a shower;

Manometer Φ 100mm;

Red warning kit;

Leaves protection for 700 mm d. fan 980*225mm;

Rear bumper for diffusor D.700mm;
